Duet 3 Motor 23CL v1.0, with brake
£182.00
Sold out
Sold out
Product Details
Duet 3 Motor 23CL v1.0, with brake
| Holding Torque | 18.9 KG/cm |
| Detent Torque | 0.86Kg/cm |
| Full Step Angle | 1.8deg |
| Max current/phase | 2.8A |
| Roto Inertia | 0.48Kg/cm2 |
| Motor Section Length | 76mm |
| Total Length | 177+-1mm (brake) 123+-1mm (no brake) |
| Ambient Temperature | -20degC to +50degC |
| Max Motor & Controller Temperature | 85degC |
| Input voltage | 12V to 48V |
| Processor | Microchip ATSAME51G19A |
| Processor features | 32-bit, 120MHz ARM Cortex-M4F, 512Kb flash, 192Kb RAM, hardware single precision floating point unit |
| Networking/Comms | CAN-FD bus for connection to the Duet 3 Mainboard. Optional on-board CAN-FD bus termination. |
| On-board stepper driver | 1x TMC2160A |
| Stepper driver features | SPI controlled, can be run in closed loop, assisted open loop, or open loop mode |
| Encoder Inputs | Hall effect, 14-bit resolution |
| Temperature monitoring | 1x on-board thermistor and processor temperature available for temperature monitoring |
| Closed loop control monitoring | Real-time performance of the closed loop control data is available for local action or remote monitoring |
These Motors are specially ordered and you must contact us prior to any orders as postage will include certain customs and import charges, as they are normally shipped direct from LDO Motors in China.
